3D wall panel Järnvik 269 Vermor 122x12x2600 mm

Product code: JVWP-269-MAR

EAN: 6430049657509

Stylish and cost-effective interior solution

Järnvik 3D wall panels offer a completely new and cost-effective way to create stunning wall solutions. With 3D wall panels, you can achieve the stylish look of popular slat walls with minimal effort and lower costs, without painting and hours of labor.

3D wall panels can be used as part of a wall, for entire walls, or even on the ceiling. The panels add a sense of space to the room visually.

These products are completely waterproof, free of harmful substances and heavy metals, recyclable, and very easy to install. The panels are highly durable and easy to keep clean.

The panels feature a stylish 3D surface texture that adds life and visual appeal to any space. They are the perfect choice for living areas, TV walls, bathrooms, offices, reception areas, and many other spaces.

Low/wide-profile, stylish tongue-and-groove wall panel with a 3D design featuring a marble-like stone pattern. It can be installed vertically or horizontally. Completely waterproof, free from harmful substances, made of polystyrene. Wear-resistant / does not scratch easily. Easy and quick to install.

For a neater finish, it is recommended to use separate end pieces during panel installation (additionally):

End piece male Järnvik 269 Vermor 42 x 12 x 2600 mm (JVWP-269-MAR-CMU; EAN: 6430049657516) 6,78 .-

End piece female Järnvik 269 Vermor 27 x 12 x 2600 mm (JVWP-269-MAR-CMN; EAN: 6430049657523) 6,78 .-

Technical information:

Width: 122 mm
Height: 12 mm
Length: 260 cm
1 pc = 0.3172 m2
19 pcs =  6,02 m2

3D Wall Panel Installation

1. Smooth the wall if necessary and remove any wallpaper remnants, etc. If needed, create a separate framework. Consider the need for a separate framework on a case-by-case basis. The framework facilitates the potential dismantling of the wall panels.
2. Cutting Panels
   Use a circular saw with a blade speed of 5000-6000 rpm and a fine-toothed blade (minimum 60T, recommended 100T) to cut the panels. Ensure the ends of the panels are straight by always trimming them with the saw.
3. a. Vertical Installation
   Always install with the male tongue first. If installing from corner to corner, separate end pieces are not needed; instead, cut the last panel lengthwise to the correct width. If the panels are not installed along the entire wall, start the installation with a male end piece. If there is an external corner on the wall, always start the installation from the external corner with a male end piece and cut the last panel lengthwise to the correct width.
   b. Horizontal Installation
   Always install with the male tongue first. When installing horizontally, the direction is always from bottom to top. When installing panels horizontally, the installation ends with a female end piece at the desired height, and no male end piece is needed.
4.  Attaching Tongue-and-Groove Panels
   Attach the tongue-and-groove panel with glue and nails to the surface to be installed. Apply glue along the entire back of the panel and place the panel in position. Finally, secure the panel with a nail gun on the male tongue side at approximately 40 cm intervals. Nail close to the edge so that the nail holes are hidden under the female tongue of the next panel. Always install from left to right, with the male tongue first. When installing on a stone surface, only glue (such as Wurth Power Tack or equivalent) can be used.

For installation on a concrete wall, it is recommended to use Wurth Power Tack or Casco XtremeFix installation adhesive or equivalent. When installing on a wooden or sheet surface where nailing is possible, it is recommended to use Wurth Installation Adhesive Pro 140 or equivalent.

The wall panel can also be glued to a separate backing board, which can then be installed as a whole on the wall, for example, by screwing it in place.

Panel joints are not recommended, but the panel can be installed with a butt joint. Try to place the joint in the least noticeable location.

NOTE: Always plan the installation carefully in advance by calculating the panel progression and taking any corners into account. If the panels are not installed from corner to corner, always factor in the impact of the end pieces on the progression to achieve the desired result and ensure the panels are positioned as planned.
