MIC+130/DIU/TC ultrasonic sensor, 9-30DC, M30, with display, 200-2000MM, PNP + 0-10V/4-20MA, M12 plug, IP67

The mic+ Sensor with one analogue output and one switching output measures the distance to an object within the detection zone contactless. A signal proportional to distance is created and the switching output is set according to the adjusted detect distance.

Technical information:

Model: mic+130/DIU/TC
Blind zone: 200 mm
Operating range: 1300 mm
Maximum range: 2000 mm
Supplier: Microsonic
Power supply: 9-30V DC
Series: mic+
Measurement range: 200-2000 mm
Working temperature: -25˚…+70˚C
Protection class: IP67
Housing: Metal/plastic
Connection type: M12 plug
Output: PNP + 0-10V/4-20mA
Shape: Cylinder
Diameter: 30 mm

User manual

MIC+130/DIU/TC
