Power Distribution and Control Equipment – 8HS

Engineered for use in power distribution infrastructure, building and industrial applications as a primary distribution and control device.

Design and Construction

The equipment enclosure is manufactured from corrosion-resistant, hot-dip zinc galvanized sheet metal. The doors are coated with UV-resistant grey powder paint; optional locking mechanisms are also available. The electrical components can be put on rails or mounting plates. The equipment interior has coverings that guarantee IP2X protection, i.e., prevent the accidental touching of current carrying components during servicing. In addition, separating interior walls prevent tools or hardware from falling into other compartments and causing a short circuit.

Transport and Installation

Tests and Standards

Harju Elekter low voltage equipment complies with the following directives: low voltage LVD 2006/95/EC, electromagnetic compatibility EMCD 2004/108/EC and mechanical design MD 2006/42/EC. The products are developed to adhere to the standards IEC 60439-1, IEC 61439-2 and IEC 60439-3. The equipment also displays the CE mark.

The manufacturing processes are certified to be in compliance with the quality standard ISO 9001:2008 as well as all environmental impact aspects described in ISO 14001:2004.

• The possible functions include power distribution, lighting control, metering, and line protection.
• The power connections can be made through the base or from the top
• Fastened to the fl oor with hardware
• The door panels are coated with powder paint in a grey tone (RAL 7035)
• Type-tested
