Tylö Crown Elite 10 grey

The Crown heater is easily placed in the sauna. The floor-standing unit, with its narrow 40cm wide sides, is easy to position the unit from a corner, against a wall or against a glass front. As standard, the unique Thermosafe™ touch protection is used to protect against accidental burns. The unit has built-in lighting.

Technical specifications:

• Color: Grey (61002204)
• Panel: Elite – included
• Relay box: Not required
• Power: 10.5 kW
• Measurements (WxHxD): 365 x 806 x 365
• Sauna size (m3): 10-18
• Stone: 20kg – ordered separately
• Min. distance to wall (mm): 50 mm
• Min. distance to ceiling (mm): 1900 mm

CROWN ELITE installation

CROWN ELITE User guide

Lift out Crown
