UK1A/G2-0ESY ultrasonic sensor, 10-30DC, M18, 50-400MM, 4-20MA, M12 plug, IP67

Name: UK1A/G2-0ESY Ultrasonic Sensor, 10-30V, M18, IP67
Price: 204.05 EUR
Availability: InStock

0.0

Model with adjustable digital output Model with current or voltage analogue outputs Working area adjusting (single point teach, standard window, adjustable hysteresis) by Teach-in button suitable for all models for a fast coming into work Multifunction LED indicator: output state, echo presence, fw identification, teach block Plastic or metallic (AISI 316L) housing, M12 plug exit and PVC cable

Tnot inc. VAT.

€204.05€288.00

Amount

Add to quote

Model with adjustable digital output
Model with current or voltage analogue outputs
Working area adjusting (single point teach, standard window, adjustable hysteresis) by Teach-in button suitable for all models for a fast coming into work
Multifunction LED indicator: output state, echo presence, fw identification, teach block
Plastic or metallic (AISI 316L) housing, M12 plug exit and PVC cable

Technical information:

Model: UK1A/G2-0ESY
Supplier: Datasensing
Power supply: 10-30V DC
Series: UK1
Measurement range: 50-400mm
Working temperature: -20˚…+70˚C
Protection class: IP67
Housing: Plastic
Connection type: M12 plug
Output: 4-20mA
Shape: Cylinder
Diameter: 18 mm

PDF

UK1A/G2-0ESY ultrasonic sensor
