UK1A/GP-0ESY ultrasonic sensor, 10-30DC, M18, 50-400MM, pnp, NO/NC, M12 plug, IP67

Model with adjustable digital output
Model with current or voltage analogue outputs
Working area adjusting (single point teach, standard window, adjustable hysteresis) by Teach-in button suitable for all models for a fast coming into work
Multifunction LED indicator: output state, echo presence, fw identification, teach block
Plastic or metallic (AISI 316L) housing, M12 plug exit and PVC cable

Technical information:

Model: UK1A/GP-0ESY
Supplier: Datasensing
Power supply: 10-30V DC
Series: UK1
Measurement range: 50-400mm
Working temperature: -20˚…+70˚C
Protection class: IP67
Contact: 1 NO + 1 NC
Housing: Plastic
Connection type: M12 plug
Output: PNP
Shape: Cylinder
Diameter: 18mm

PDF

UK1A/GP-0ESY ultrasonic sensor
